Dali Dimmer for COB lights led strip Dali switch Wall Mount dali signal Dimmer

Product features

• Adopt latest DALI standard protocol IEC62386
• Support switch and dimming function.
• DALI bus supply power.
• Easy to set DALI address.
• Support group, unicast, broadcast mode.

Technical specs

Name: DALI knob panel

Working temperature: -20℃-55℃

Model: E6-DA1

Dimensions: L86×W86×H50(mm)

Power Supply: DALI power

Package size: L106×W106×H60(mm)

Output signal: DALI

Weight(G.W.): 235g

Dimming style: Spin

Static current:6mA@16V

Standby current:4mA@16V
