Led Strip Controller DC12-24V 5A/4CH 2.4GHz RF wireless RGBW strip controller

Remote

Receiver

Feature

• Match with all Skydance's 2.4G single color, dual color and RGB/RGBW remote control,
• One RF controller accept up to 10 remote control.
• When using with RGB/RGBW light, built in 10 dynamic mode, include jump or gradual change style.
• Auto - transmitting function: Receiver could transmit signal to another receiver within 30m, and the total remote control distance can up to 100m.
• Synchronize on dynamic mode.
• Connect with external push switch to achieve on/off and dimming function.

Technical parameter

• Output signal: RF(2.4GHz)
• Working volatage: 3VDC(AAA*2pcs)
• Working current:＜20mA
• Standby current: ＜10μA
• Standby time: 6 months
• Remote distance: 30m
• Working temperature:-30℃-55℃
• Dimension: L122×W53×H17.5(mm)
• Weight:135g

V4.pdf
